Trek Madone SL 5 Gen 8

Trek Madone SL 5 Gen 8
  • Color: Gloss Dark Star/Matte Deep Smoke
  • Color: Matte Lavender Haze/Deep Smoke
$3,499.99
Color:
Size: Select size
Wheel Size: 700c
Please select options Unavailable
Order now and pick up in-store for free

Details

Madone SL 5 Gen 8 is a lightweight aero road bike that brings elite racing tech to a lower price point. It offers similar aero benefits to the pricier Madone SLR Gen 8 models, but with a more economical OCLV 500 Carbon layup and two-piece cockpit with hidden cable routing. A Shimano 105 groupset, alloy handlebars, and alloy wheels keep the price down while still delivering clean mechanical shifting you can trust.

Frame SizeX-SmallSmallMediumMedium/LargeLargeX-Large
Wheel Size 700c 700c 700c 700c 700c 700c
Seat Tube (cm / in) 40.4 / 15.91 44.0 / 17.32 47.6 / 18.74 51.2 / 20.16 54.8 / 21.57 60.9 / 23.98
Seat Tube Angle (degrees) 73.8 73.8 73.6 73.4 73.4 73.4
Head Tube Length (cm / in) 10.0 / 3.94 12.1 / 4.76 13.6 / 5.35 15.0 / 5.91 17.2 / 6.77 20.1 / 7.91
Head Tube Angle (degrees) 71.6 72.2 72.9 73.5 73.8 73.9
Top Tube Effective (cm / in) 51.7 / 20.35 53.2 / 20.94 54.5 / 21.46 55.7 / 21.93 56.8 / 22.36 58.4 / 22.99
Bottom Bracket Drop (cm / in) 7.2 / 2.83 7.2 / 2.83 7.0 / 2.76 7.0 / 2.76 6.8 / 2.68 6.8 / 2.68
Chainstay Length (cm / in) 41.0 / 16.14 41.0 / 16.14 41.0 / 16.14 41.0 / 16.14 41.1 / 16.18 41.2 / 16.22
Fork Offset (cm / in) 5.0 / 1.97 4.5 / 1.77 4.5 / 1.77 4.0 / 1.57 4.0 / 1.57 4.0 / 1.57
Trail (cm / in) 6.1 / 2.40 6.2 / 2.44 5.8 / 2.28 5.9 / 2.32 5.7 / 2.24 5.7 / 2.24
Wheelbase (cm / in) 97.1 / 38.23 97.6 / 38.43 98.1 / 38.62 98.0 / 38.58 99.0 / 38.98 100.7 / 39.65
Standover (cm / in) 70.4 / 27.72 73.4 / 28.90 76.2 / 30.00 79.0 / 31.10 82.0 / 32.28 86.3 / 33.98
Reach (cm / in) 37.0 / 14.57 37.8 / 14.88 38.4 / 15.12 38.9 / 15.31 39.4 / 15.51 40.2 / 15.83
Stack (cm / in) 50.7 / 19.96 53.0 / 20.87 54.6 / 21.50 56.2 / 22.13 58.2 / 22.91 61.0 / 24.02
Saddle Rail Height Min (Short Mast) (cm / in) 54.9 / 21.61 58.5 / 23.03 62.1 / 24.45 65.7 / 25.87 69.3 / 27.28 75.4 / 29.69
Saddle Rail Height Max (Short Mast) (cm / in) 61.2 / 24.09 64.8 / 25.51 68.4 / 26.93 72.0 / 28.35 75.6 / 29.76 81.7 / 32.17
Saddle Rail Height Min (Tall Mast) (cm / in) 59.2 / 23.31 62.8 / 24.72 66.4 / 26.14 70.0 / 27.56 73.6 / 28.98 79.7 / 31.38
Saddle Rail Height Max (Tall Mast) (cm / in) 65.4 / 25.75 69.0 / 27.17 72.6 / 28.58 76.2 / 30.00 79.8 / 31.42 85.9 / 33.82
Frame SizeX-SmallSmallMediumMedium/LargeLargeX-Large
Rider Height (cm) 143 – 158 158 – 162 162 – 173 173 – 179 179 – 188 188 – 213
Rider Height (in) 4'8" – 5'2" 5'2" – 5'4" 5'4" – 5'8" 5'8" – 5'10" 5'10" – 6'2" 6'2" – 7'0"
Inseam (cm) 67 – 74 74 – 76 76 – 81 81 – 84 84 – 88 88 – 100
Inseam (in) 26" – 29" 29" – 30" 30" – 32" 32" – 33" 33" – 35" 35" – 39"

Specs

Frame 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle
Fork Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Rims Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23mm width, Presta valve
Hubs Front: Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle Rear: Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
Tires Bontrager Aeolus Pro, Tubeless Ready, aramid bead, 120tpi, 700x28mm
Bottom Bracket Praxis, T47 threaded, internal bearing
Crankset X-Small, Small: Shimano 105 R7100, 50/34, 165mm length, Medium, Medium/Large: Shimano 105 R7100, 50/34, 170mm length, Large, X-Large: Shimano 105 R7100, 50/34, 172.5mm length
Shifters Shimano 105 R7120, 12 speed
Front Derailleur Shimano 105 R7100, braze-on, down swing
Rear Derailleur Shimano 105 R7100, 36T max cog
Cassette/Freewheel Shimano 105 7101, 11-34, 12 speed
Chain Shimano SLX M7100, 12 speed
Brakes Shimano 105 hydraulic disc, flat mount
Rotors Shimano CL700, centerlock, 160mm
Handlebars X-Small: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 36cm control width, 40cm drop width, Small, Medium: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 38cm control width, 42cm Medium/Large: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 40cm control width, 44cm, Large: Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop, 42cm control width, 46cm
Tape/Grips Trek EcoTack
Stem X-Small: Trek RCS Pro, -7 degree, 80mm length, Small, Medium: Trek RCS Pro, -7 degree, 90mm length, Medium/Large, Large: Trek RCS Pro, -7 degree, 100mm length, X-Large: Trek RCS Pro, -7 degree, 110mm length
Seatpost Madone areo carbon seatpost, 0mm offset, short length
Saddle Bontrager Aeolus Elite, austenite rails, 145mm width

* Subject to change without notice.

Part Numbers

Option UPC MPN
Gloss Dark Star/Matte Deep Smoke / X-Small / 700c 197216237495 5337860
Gloss Dark Star/Matte Deep Smoke / Small / 700c 197216237501 5337861
Gloss Dark Star/Matte Deep Smoke / Medium / 700c 197216237518 5337862
Gloss Dark Star/Matte Deep Smoke / Medium/Large / 700c 197216237525 5337863
Gloss Dark Star/Matte Deep Smoke / Large / 700c 197216237532 5337864
Gloss Dark Star/Matte Deep Smoke / X-Large / 700c 197216237549 5337865
Matte Lavender Haze/Deep Smoke / X-Small / 700c 197216237679 5338933
Matte Lavender Haze/Deep Smoke / Small / 700c 197216237686 5338934
Matte Lavender Haze/Deep Smoke / Medium / 700c 197216237693 5338935
Matte Lavender Haze/Deep Smoke / Medium/Large / 700c 197216237709 5338936
Matte Lavender Haze/Deep Smoke / Large / 700c 197216237716 5338937
Matte Lavender Haze/Deep Smoke / X-Large / 700c 197216237723 5338938
